Alloy Quartz Crystal for High Stress Deposition - EQ-QC-ALLOY-LD
Alloy Quartz Crystal for High Stress Deposition - EQ-QC-ALLOY-LD
Dimension
14 mm Dia.
Electrode Material
Alloy
Sensor and Monitor
MTI thin film thickness monitor - EQ-TM106-LD
Life Time
Quartz crystals are consumable parts, no warranty of any kind
Please note the crystal life form the thickness monitor
Typical Applications
Designed for high-stress depositions, such as optical coating with dielectric materials and semiconductor processes with high-stress materials
DC Sputtering
RF Sputtering
Thermal Evaporation
Ion Plating
Anticorrosive Coating
Application Notes
Choose the quartz crystal with the right electrode material for your application - gold, silver, alloy:
Recommend gold electrode crystals for most applications
Silver electrode crystals work well for processes with high heat loads, such as sputtering
Alloy electrode crystals are recommended for high-stress deposition, such as optical coating with dielectric materials and semiconductor processes with high-stress materials
Notes
The recommended distance from source to sensor is 12 inch
Avoid source splatter and heat load to the crystal.
Additionally, please take notice of the bend radius dependent on the sensor that is ordered.
